1600 tons Trimming press TMP Voronezh K9542
The TMP Voronezh K9542 is a heavy-duty 1600 tons trimming press used in forging lines for removing flash and finishing hot-forged parts after impression die forging. With a long 630 mm slide stroke, a large 1600 × 1600 mm bolster and slide, and a rigid upright window, the machine is suitable for high-load trimming of large forgings, where die alignment, daylight and stable ram guidance directly affect edge quality and tool life.
- Photo set available (see gallery).
- We can arrange inspection, dismantling, packing and international shipping (subject to availability).
- Please mention the machine ID when requesting an offer: TRG-1600-TP-01.
In industrial forging shops, a trimming press is a dedicated machine that performs flash trimming and final separation operations after hot forging. This TMP Voronezh model K9542 belongs to the heavy tonnage class, intended for large dies and high cutting forces where a stable frame, controlled slide travel and repeatable stroke behavior are required for consistent part geometry. The 810 mm maximum daylight (distance between bolster plate and slide) and 220 mm adjustment help adapt the setup to different trim die heights and tooling packages.
Production efficiency depends on both throughput and controllability. The K9542 supports up to 16 continuous strokes per minute (and up to 12 single strokes), which is useful when trimming must match the rhythm of a forging press or transfer line. The 110 kW main motor and the substantial machine mass contribute to stable operation under peak loads, reducing vibration and helping maintain cutting accuracy during repeated cycles.
If you need an alternative trimming press in a similar tonnage range (for large forgings, ring and flange parts, heavy housings and other hot-forged components), contact us — we can advise on available options and organize inspection, dismantling and export documentation.
