1600 ton Knuckle joint press Agostino Colombo G1600

1600 ton Knuckle joint press Agostino Colombo G1600

Machine ID: TRG-630-HYD-01

Nominal capacity 1600 t

Type Knuckle joint press

Manufacturer Agostino Colombo

Location EU plant

Price on request. We will calculate with dismantling and logistics.

Request a quote Clarify price

Used 1600 ton knuckle joint coining press Agostino Colombo G1600 with 1060 × 900 mm table, 135 mm stroke and 635 mm shut height, suitable for precision coining and calibration in automotive and general engineering. These values match published data for G1600 units in European inventories.

Full technical inspection and dismantling on request.
Packaging and export documentation for EU and overseas customers.
Modernization and automation options can be discussed.

For detailed photos and full technical specification, please contact us and mention the machine ID. Multiple listings confirm this G1600 configuration with 1600 ton capacity and 45 HP drive.

Technical description

The Agostino Colombo G1600 is a mechanical knuckle joint coining press designed to deliver maximum force near bottom dead center, improving surface finish and dimensional accuracy for demanding cold forming operations. Typical applications include coining, calibration and fine stamping of high-value components.

The press can be supplied with dismantling, loading, transport securing, commissioning support and export paperwork from an EU location. This configuration mirrors machines currently advertised in Italy and other European markets.

Technical data

Manufacturer Agostino Colombo

Model G 1600

Nominal capacity 1600 ton

Table size 1060 × 900 mm

Stroke 135 mm

Shut height 635 mm

Ram adjustment 20 mm

Side opening 400 mm

Motor 45 HP

Specs match published data for 1600 tons Press Knuckle Joint Coining Colombo Agostino G1600, including table size, stroke, shut height, ram adjustment, side opening and motor power.
